You may have seen disclaimers on zmanim calendars warning of up to a 2 minute inaccuracy due to weather and atmospheric conditions. Atmospheric refraction from the earth’s atmosphere, causes the sun to be visible on average about 3 minutes earlier at sunrise, and about 3 minutes later at sunset (compared to a vacuum) due to the atmosphere bending the sunlight upwards towards the viewer. The 3 minutes is only an average, and it can swing widely due to weather and atmospheric conditions. The typical variance caused by “non-average” atmospheric conditions would usually be within 2 minutes, resulting in the 2 minutes mentioned in the disclaimers. This 2 minute variance is during usual conditions, though there are conditions that would greatly increase this time.
When the sun’s rays traveling through the vacuum of space hit the earth atmosphere, they slow down and bend upwards towards the observer resulting in the sun being visible earlier (than in a vacuum) in the morning, and later at sunset.Refraction of the sun’s rays is not a one stage refraction, but as the sun passes through increasingly dense layers of atmosphere, the amount of refraction increases with each thicker layer. This can be seen in the diagram of refraction at sunset above. The apparent position of the sun near sunset in the image (exaggerated in the image) is height of the sun as it appears to the user, though in reality the sun is below the horizon. Refraction can easily be observed by looking at a straw in a partially filled glass. The straw appears to bend (or be broken) at the point it enters the water. This is due to increased refraction in water versus air.
Complexity in Calculating Refraction
Since the amount of refraction depends on the pressure (the more dense the atmosphere is, the greater the refraction), temperature (hot air is less dense and refracts less) and to a lesser degree humidity (water vapor in the air impacts the refraction) in each layer of the atmosphere, calculating refraction is complex and requires very detailed meteorological information on the current conditions in each layer of the atmosphere in the area being computed. This can’t be done accurately in advance, and even calculations for the current day require readings from weather balloons at multiple elevations for accurate measurement, something not very practical (though the Lakewood vasikin minyan (likely done elsewhere as well) manually adjusts the hanetz hachama time each morning based on the weather). For this reason, zmanim (as well as civil sunrise and sunset) calculations usually use a global average refraction of 34′ of a degree, or 0.5666°. The global average atmospheric refraction accounts for sunrise being between 3:01 minutes earlier (during the solstice), and 2:29 minutes earlier (during the equinox) in Yerushalayim, as opposed to the value in a vacuum (the difference depends on where in the world you are, in Lakewood, NJ the range is 3:29 – 2:57). This average atmospheric refraction is not very accurate but is commonly used since it is complex to calculate local averages. More accurate refraction figures can be calculated for local and seasonal atmospheric models, and these have been shown to be accurate to within 15 seconds 90% of the time in the case of summer and winter subtropical models used in a study in Israel. See Using a Digital Terrain Model to Calculate Visual Sunrise and Sunset Times by Rabbi Chaim Keller and Dr. John K. Hall for additional details.
Inversion and the Novaya Zemlya Effect
Under usual conditions, the atmosphere gets colder at elevation, with the warmest air being closest to earth. An inversion condition is where there is a layer of cold air under a layer of warmer air. When there is an inversion over a large area (greater than 400 km), the solar rays get ducted in the lower colder air layer (see image below) and produce an extreme refraction. This is known as the Novaya Zemlya effect and produces a solar mirage resulting in the somewhat visually distorted sun being visible much earlier than expected (see top image).While typically a phenomena in the polar regions, a study by the University of Calgary showed that refraction can have a significant affect on zmanim even in non-polar areas. In the 2003 study (Variability in the Astronomical Refraction of the Rising and Setting Sun), they observed that the sunrise on January 10, 1991 appeared almost 12 minutes earlier than expected. The paper mentions:
On rare occasions, the Sun appeared to rise much earlier or set much later than predicted by such publications as the Tables of Sunrise, Sunset, and Twilight (USNO 1962). In our study, the sunrise of 1991 January 10 was almost 12 minutes early. This phenomenon is known as the Novaya Zemlya solar mirage (Lehn 1979). It appears to be caused by a geographically extensive temperature inversion within the boundary layer of the atmosphere. The resulting vertical density profile causes the sunlight to be ducted around the curvature of the Earth. For the purpose of this study, we defined anomalously large astronomical refraction to be an event with refraction greater than 1°. A total of 12 anomalous events were recorded (2.9%).
While these typically occur in cold areas, they can happen in other areas as well. The study authors mention that
The majority of the anomalous events took place in the cold months. Nine of the 12 events occurred between November 1 and April 30, with January having five events. At the time of the events, the average surface temperature was -10.9°C, and all events occurred with surface-inversion conditions. Surface inversions tend to form with overnight surface radiative cooling through a dry atmosphere. Typically, they persist into the early morning, even after sunrise. Even though most of the events took place in the cold parts of the year, the data suggest that the Novaya Zemlya solar mirage may not be an exclusively cold-weather or polar phenomenon. Four of the events occurred with a surface temperature greater than 0°C. One event took place 2 days after the summer solstice.
Refraction at Sunrise VS Sunset
The University of Calgary study found that extreme refraction is an order of magnitude more common at sunrise than sunset. The reason for the difference between sunrise and sunset is that
This may be because the lower atmosphere is better mixed during the day as a result of solar heating leading to a dry adiabatic lapse rate in the boundary layer. Anomalously large astronomical refraction events the “Novaya Zemlya solar mirage” occurred about 3% of the time and were an order of magnitude more common at sunrise than sunset.
That said, The Novaya Zemlya effect does occur at sunset and in warm climates as seen in this video of sunset in San Francisco. Sadly, the video does not include information on how long it delayed sunset.
Halachically sunrise and sunset times depend on when we can see the sun, and not when it is at the horizon. As mentioned above, the average global refraction of 34′ results in sunrise appearing about 3 minutes earlier and sunset 3 minutes later later than in a vacuum, and this refraction (or other similar refraction values) is what is used in all calendars (both halachic and civil). The fact that there is such potential for variation in weather conditions, and that the global average is likely not what is present where the zmanim are being calculated, is the reason that many luchos (zmanim calendars) have disclaimers about accuracy. Many calendars round off their zmanim without showing seconds due to the inability to accurately calculate zmanim because of refraction variations. Lahalacha the impact of earlier or later sunrise is limited to vasikin minyanim. A separate article may be needed to actually discuss sof zman krias shema and other zmanim’s relation to sunrise and sunset VS the actual position of the sun in the sky (1/4 of the way across its path for sof zman krias shema). The halachic impact of refraction at sunset is much greater since it impacts the day/night boundary, but those are much rarer.
Now to the big question, does extreme refraction such as the Novaya Zemlya effect impact zmanim? The fact that it rarely impacts sunset, means that it almost academic since predicting the inversion before a vasikin minyan starts is impractical. In a conversation with one posek a number of years ago, he felt that the Novaya Zemlya Effect should not impact zmanim lahalacha due to the fact that unusual occurrences should not be factored in, and because the distorted sun is not considered the sun as far as zmanim. I would appreciate being notified if anyone receives a psak halacha on this question.
